Vendor:Z-Cam

Z CAM E2C 4K CINEMA CAMERA

$1,499.00 AUD

Pairs well with
Out of stock — call us to check availability.

1-Year Warranty

Out of stock

Pickup currently unavailable at Shop Front

The Z CAM E2C Professional 4K Cinema Camera shoots UHD 4K at up to 29.97 fps, as well as HD up to 59.94 fps, and records to an SDXC Class 10 card (not included). The camera features a 4/3" sensor with 10-bit color support and nominal 11.5 stops of dynamic range. The camera supports recording video in MOV/MP4 using H.265 for 10-bit recording, while H.264 supports 8-bit recording, and a recent firmware update allows the camera to record in the ZRAW format. Audio is recorded in 24-bit 48 kHz using AAC or PCM (PCM for MOV format only).

You can use an available iOS app to control the camera via Wi-Fi and to view a live image preview. You can also control it locally by the buttons along the front edge of the camera. The camera powers via PoE, an LP-E6-series battery (not included), or via a DC input port. An included LEMO to D-Tap power cable allows you to power the camera from a D-Tap source. An optional AC to DC power adapter can also power the camera.



Features:

  • 4K @ 30fps, 10-bit color
  • 4/3" CMOS sensor
  • 11.5 stops dynamic range
  • Gigabit Ethernet for data, control & live streaming*
  • iOS app for control setting & live preview
  • POE supported

*Requires Z CAM software running on PC

SUPPORTED LENSES

Panasonic Lumix 14mm f/2.5 G

Panasonic Leica DG Summilux 15mm f/1.7 ASPH

Panasonic Lumix G Vario 7-14mm f/4 ASPH

Panasonic Lumix G Vario 14-140mm f/3.5-5.6 ASPH. POWER O.I.S.

Panasonic Lumix G 25mm f/1.7 ASPH.

Panasonic Lumix G 42.5mm f/1.7 ASPH. POWER O.I.S. Lens

Panasonic Lumix G X Vario 12-35mm f/2.8 II ASPH. POWER O.I.S.

Panasonic Leica DG Vario-Elmarit 8-18mm f/2.8-4 ASPH.

Panasonic Leica DG Macro-Elmarit 45mm f/2.8 ASPH. MEGA O.I.S

Lumix G X Vario 14-42mm f/3.5-5.6 Power O.I.S.

Sigma 19mm F2.8 DN Art

Olympus M.Zuiko Digital ED 8mm f/1.8 Fisheye PRO

Olympus M.Zuiko Digital ED 12mm f/2

Olympus M.Zuiko Digital ED 17mm f/1.2 PRO

Olympus M.Zuiko Digital ED 12-40mm f/2.8 PRO

Olympus M.Zuiko Digital ED 45mm f/1.2 PRO

Olympus M.Zuiko Digital ED 75mm f/1.8 Lens

Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ

Olympus M.Zuiko Digital ED 25mm f/1.2 PRO

Olympus M.Zuiko Digital ED 60mm f/2.8 Macro

Olympus M.Zuiko Digital ED 60mm f/2.8 Macro

Olympus M.Zuiko Digital ED 60mm f/2.8 Macro

Olympus M.Zuiko Digital ED 30mm f/3.5 Macro

Olympus M.Zuiko Digital ED 40-150mm f/2.8 PRO

Olympus M.Zuiko Digital ED 7-14mm f/2.8 PRO

Olympus M.Zuiko Digital ED 12-100mm f/4 IS PRO

Olympus M.Zuiko Digital ED 300mm f/4 IS PRO

TECHNICAL SPECIFICATIONS

Camera Features

Sensor Type 4/3" CMOS Sensor
Sensor Size 17.56 x 13.11mm
Effective Pixels 16.83M
Dynamic Range 11.5 Stops (Z-Log2)
Lens Mount Micro Four Thirds
Microphone Built-in Stereo Microphone
Recording
Resolution & Frame Rate 3840 x 2160 @ 29.97 / 25 / 24 / 23.98 fps
  2880 x 2880 @ 29.97 / 25 / 24 / 23.98 fps
  1920 x 1080 @ 59.97 / 50 / 29.97 / 25 / 24 / 23.98 fps
Color Bit Depth 10-bit (H.265) / 8-bit (H.264)
Video Encoder * H.265 main 10 profile / H.264 high profile
Audio Format 24-bit 48 kHz
Audio Encoder AAC / PCM (for MOV only)
File Format MOV / MP4
Record Mode Video / Time Lapse Video
Settings
ISO Auto, Manual (800 ~ 25600)
Shutter Shutter Speed: Auto, Manual (up to 1/8000”) or
  Shutter Angle: Auto, Manual (1° ~ 360°)
White Balance Auto, Preset, Manual (2300K ~ 7500K)
Focus Mode MF / AF / CAF
Image Brightness / Contrast / Saturation / Sharpness
LUT Rec.709 / Z-Log2 / FLAT / HLG
Audio Audio In / Audio Out Level
Time Code Current Time / Manual Input
Storage

Media SDXC Class 10 SD card. Recommend to use UHS-I Speed Class 3 (U3) ones for 4K video recording
File System exFAT
Connectivity
HDMI HDMI 2.0 Type A
USB USB 3.0 Type C for camera control & data transfer only
Remote Control 2.5 mm jack socket (Sony LANC compatible)
Audio-in 3.5 mm stereo jack socket for active microphone only
Audio-out 3.5 mm stereo jack socket
Wi-Fi 802.11n, 2.4G with external antenna port
Ethernet Gigabit Ethernet port for control, setting & live streaming, POE supported
Power
Battery Canon LP-E6 compatible (Battery not included)
External Power Supply DC 12V/1.5~5A, with power cable with D-TAP plug & D-TAP/DC connector (AC/DC adapter not included)
Power Over Ethernet (POE) 802.3at/af compatible, need CAT5E or above Ethernet cable
Physical
Material Aluminum Alloy
Weight 668 g (without lens)
Dimensions (W x H x D) 91.2 mm x 83.9 mm x 89.1 mm (without lens)
Environment
Storage Temperature -20 °C ~ 60 °C
Operation Temperature 0 °C ~ 40 °C
