Vendor:Blackmagic Design
Pairs well with
1-Year Warranty
This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.
Couldn't load pickup availability
Pickup currently unavailable at Shop Front
Delivery Australia-wide
Share:
Key Features
Requires a minimum of two units—one for encoding the signal and one for decoding the signal.
TICO encoding is a visually lossless compression designed to let you distribute video across an IP network.
The unit supports signals up to 1080p60 over a standard Ethernet connection. For support of signals up to 12-G SDI (4K DCI or 4K UHDF), an optional 10G fiber optic Ethernet LC connector is required.
Blackmagic Videohub Software can be used on Windows or Mac OS computers to turn them into a router server that can manage the connections between multiple units so you can build a large custom sized router on your network.
Supports AC voltage using an optional IEC cable (Blackmagic units do not ship with a power cable) or you can power it via PoE+ with a compatible router.
Setup is done via built-in DIP switches, Blackmagic Teranex setup software, or an optional Teranex Mini Smart Panel with LCD screen.
You can control your Mini 12G-IP via the optional Teranex Mini Smart Panel with LCD screen or Blackmagic Video Hub software.
Embedded audio is supported—there are no separate audio inputs/outputs.
Blackmagic Teranex setup and Video Hub software is included on the SD card that ships with your unit.
Key Specs
Input 1x BNC (12G-SDI) Output 2x BNC (12G-SDI)
SDI Input (10-Bit 4:4:4/4:2:2 RGB, YUV) 4096 x 2160 at 23.98/24/25 fps 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps 2048 x 1080 at 23.98/24/25 fps 2048 x 1080PsF at 23.98/24/25 fps 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080PsF at 23.98/24 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps SDI Output (10-Bit 4:4:4/4:2:2 YUV) 4096 x 2160 at 23.98/24/25 fps 3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps 2048 x 1080 at 23.98/24/25 fps 2048 x 1080PsF at 23.98/24/25 fps 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080PsF at 23.98/24 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps
NTSC, PAL
Encoding via TICO 4096 x 2160 Decoding 4096 x 2160
macOS Windows
Inputs/Outputs
Input/Output 1x RJ45
1x SFP Slot
Format Support
LAN (RJ45)/SDI
No
Standards
ITU-R: BT.601/BT.656 SMPTE: 259M/292M/296M/310M/425M
IP Streaming
Hardware
Single Slot: SD (Unspecified Type)
Power
1x RJ45 (48 VDC ) Input 1x IEC C14 Input
PoE+ 802.3at
Device: 90 to 240 VAC (16 W)
General
32 to 104°F / 0 to 40°C at 0 to 90% Humidity
-18 to 140°F / -28 to 60°C
6.69 x 5.51 x 1.75" / 16.99 x 14 x 4.45 cm
1.28 lb / 581 g
